METHODOLOGY FOR FIRE PROOFING REQUIREMENT QUALITATIVE ASSESSMENT STUDY

Client: M/s ___ Title: METHODOLOGY FOR FIRE PROOFING REQUIREMENT QUALITATIVE ASSESSMENT STUDY
20/01/2026	A	Draft	SS	YSG	YSG
Date	Rev	Remarks / Revision Summary	Prepared	Checked	Approved
			HSE RMSPL
REVISION RECORDS





DISCLAIMER

HSE Risk Management Services Private Limited accepts no liability or responsibility whatsoever for it in respect of any use of or reliance upon this Methodology by any third party. Copying this Methodology without the permission of HSE Risk Management Services Private Limited is not

permitted.

OBJECTIVE

The purpose of Fire Proofing Requirement Qualitative Assessment is to establish the criteria for the proper selection of (a) the proper fireproofing material; (b) the structures and equipment that should receive fireproofing protection; and (c) the extent of the fireproofing application.

The primary objective is to provide sufficient protection to allow for the following actions:

• Prevent the collapse of structures and equipment and thereby, prevent the release of flammable fluids from failed equipment that could result in the escalation of a fire event.
• Protect occupied areas from structural collapse; as well as to protect escape routes that allow for an orderly evacuation of personnel from the affected area.
• Protect critical shutdown and control circuits, maintaining integrity of emergency equipment and thus, allowing for an orderly shutdown.
• Provide protection of assets and limit the exposure to consequential damage, whether from equipment replacement or business interruption.

SCOPE

The qualitative assessment of fireproofing requirements focuses on identifying where, what type, and to what extent fireproofing is needed based on fire exposure scenarios, equipment criticality, and safety objectives, without performing detailed quantitative fire calculations.

Reference for FPRQA Methodology

1. API RP 2218 – Fireproofing Practices in Petroleum and Petrochemical Processing Plants

ORDER OF PRECENDENCE

1. API RP 2218 – Fireproofing Practices in Petroleum and Petrochemical Processing Plants
2. As per Client Guidelines
3. National & International reference books.

Proposed Methodology

1. Introduction
2. The fire proofing assessment methodology presented in this document is based on a qualitative, risk-based fire scenario envelope methodology. The approach is aligned with established oil and gas industry practices and is intended to identify the need, extent, and rating of passive fire protection without performing detailed quantitative fire or thermal radiation modeling.
   1. Methodology
3. Step 1: Identification of Fire Potential Equipment
4. Process equipment is screened to identify fire potential based on:
5. Inventory of flammable or combustible fluids
6. Operating pressure and temperature
7. Flow rate and leak potential
8. Heat of combustion
9. Presence of lubricating oil systems
10. Based on these parameters, equipment is categorized as high or low fire potential

1. Step 2: Definition of Fire-Exposed Envelope
2. For each fire potential equipment item, a fire scenario envelope is defined. The base envelope dimensions as per API section 5.2.

1. Step 3: Determination of Fireproofing Extent and Rating
2. All structural steel, equipment supports, pipe racks, platforms, vessel skirts, and critical systems located within the fire-exposed envelope are evaluated for fireproofing. Fireproofing ratings as per API section 5.2.

1. Documents Requirement

• Latest Plot Plan in Auto Cad
• PFD & P & ID
• Basis of Design
• Equipment plan & Elevation
• List of Equipment – Equipment Support Details, Operating Pressure / Temperature, Design Pressure / Temperature, Dimensions, Equipment Class, MOC, Test Pressure, Capacity
• Line List – Line No., From, To, MOC, Insulation, Test Pressure, Nominal Pipe Size, Piping Class, Design Condition (Pressure, Max. / Min. Temperature), Velocity, Flow Rate, Phase
• Instruments List and Specialty Items
• Hazardous Area Classification Drawings
• Pipe Rack Elevation Details
• Control and Electrical System Details – Fail Safe Design Condition i.e. fail close or fail open
• Steel Surfaces – details of equipments like Vessels or Tank Shells etc. (If applicable)
• Heat and Material Balance
• ESD / BDV or related valve fail safe status
• Composition and service in the pipe line and equipment
• Insulation details of the each equipments – type of insulation design drawing of the insulation or specification of the insulation
• F & G layout on plot plan
• Heater details , if any
• List of equipments having the lubricating system , like pump / compressor if applicable then provide Volume of lubricant etc.
• Details of Vessel contain toxic material – details includes the name of chemicals
• Preferred Guidelines – Engineering Guidelines or any other specify
• FRA- fire risk Assessments for risk or radiation radius
• Safety Critical Elements and Performance Standard

1. Project Deliverables

Table 1: FPRQA Study

Sr. No.	Document Deliverable
	Executive Summary
	Document Review
	Submission of terms of reference
	Fire Proofing Methodology
	Fire Proofing Needs  The location of fire potential equipment – location of fire potential equipment  The extent of fire exposed envelop   The rating of fire proofing material  Equipment and structural fire proofing requirement  Control and electrical system fire proofing requirement   Extent of Fire Exposed Envelop for Pipe Racks  Fire proofing requirement for extended platform – 19 Nos.  Tower and vessels skirts within a fire scenario envelop  Lightweight Cementitous fire proofing
	Annexure – 1: Fire Exposed Envelop of Equipment and Fire Proofing Requirement to the Support of the Equipment
	Annexure-2: Control & Electrical Systems Fire Proofing Requirement
	Annexure-3: Fire Exposed Envelops for Steel Surfaces and Fire Proofing Requirement for Support
	Annexure 4: Fireproofing Layout Plan
	Any additional as per the scope

•
